The class DicomModifyFieldAddOnBase is dedicated to manage fields for ML modules and instances derived from DicomModifyBase to combine field handling and tag modification functionality to modify DCMTree's and to allow concatenation of them to pipelines. More...
#include <mlDicomModifyFieldAddOnBase.h>
Public Member Functions | |
| DicomModifyFieldAddOnBase (FieldContainer &fieldContainerRef, size_t numInstances=1, bool createInputModifyTagsPluginBaseConnectorField=false, bool createOutputModifyTagsPluginBaseConnectorField=false) | |
| Constructor, setting the reference of the FieldContainer managing the fields, the number of field instances to create and optionally input and output fields to create modification pipelines. More... | |
| ~DicomModifyFieldAddOnBase () override | |
| Destructor resetting connector fields if they exist. More... | |
| size_t | getNumInstances () const |
| Returns the number of instances to be created by derived fields. More... | |
| std::string | applyModifications (DCMTree::TreePtr dcmTree, const FieldContainer *treeInfos=nullptr) override |
| Applies first the changes to the dcmTree as described in DicomModifyList::applyModifications() and then calls applyModifications() on all connected input DicomModifyList objects. More... | |
| void | addFields () override |
| Add fields to field container of the FieldAddOn. More... | |
| void | handleFieldActivationChanges () override |
| Handle class changes according to Module::activateAttachments. More... | |
| FieldAddOnBase::FieldChangeState | handleFieldChanges (Field *field) override |
| Handle field notifications according to Module::handleNotification with a return of field change state. More... | |
| virtual void | inheritValues (DCMTree::Const_TreePtr) |
| Can be used to implement the copy of tag values from the given dcmTree to the fields. More... | |
| virtual std::string | checkConsistency () const |
| Checks for invalid parameters; return textual description on error, or empty string on success. More... | |
| BaseField * | getOutputModifierListFld () const |
| Provide access to output base field if it was created. More... | |
| BaseField * | getInputModifierListFld () const |
| Provide access to input base connector field if it was created. More... | |
 Public Member Functions inherited from ml::DicomModifyList | |
| DicomModifyList () | |
| Constructor creating an empty list of tag modifiers and setting the optional input plugin with a concatenated DicomModifyList. More... | |
| ~DicomModifyList () override | |
| Destructor also destroying all of its stored Modifiers. More... | |
| void | addModifier (DicomModifyBase *modifier, bool atEnd=true) |
| Add an object derived from DicomModifyBase which then will be owned (and on destruction deleted) by this. More... | |
| void | clear () |
| Makes modifier array empty and deletes all of them. More... | |
| std::vector< DicomModifyBase * > & | getModifierList () |
| Get direct access to internal list to allow callers direct manipulations which, however, must obey the restriction that ownership belongs to *this, i.e. More... | |
| const std::vector< DicomModifyBase * > & | getModifierList () const |
| Same as getModifierList() only for constant access. More... | |
| void | setInputPlugin (DicomModifyList *inputPlugin=nullptr) |
| Sets an optional plugin to be called by applyModififcations or resets it to nullptr; the input is called after the objects in _modfiers list. More... | |
| DicomModifyList * | getInputPlugin () const |
| Returns the optional plugin to be called by applyModififcations. More... | |
| Public Member Functions inherited from ml::Base | |
| Base () | |
| Constructor. More... | |
| virtual | ~Base () |
| Destructor. More... | |
| virtual Base * | deepCopy () const |
| Set addStateToTree version number that can be accessed via getAddStateVersion() More... | |
| bool | isOfAllowedType (const std::vector< const RuntimeType * > &types) const |
| Check if this object's type is equal to or derived from one of the types given in the argument. More... | |
| virtual bool | isRefCountedBase () const |
| Returns if the instance is derived from RefCountedBase. More... | |
| virtual std::string | detailString () const |
| Return a string describing this object. More... | |
| virtual bool | implementsPersistence (PersistenceInterface) const |
| Override this method to declare which persistence interfaces are implemented by your derived class. More... | |
| virtual std::string | persistentState () const |
| Returns a string describing the object's internal state. More... | |
| virtual void | setPersistentState (const std::string &state) |
Restores the object's internal state from a string that had been previously generated using persistentState(). More... | |
| virtual void | addStateToTree (TreeNode *) const |
| Attaches the object state as children of the given parent node. More... | |
| virtual void | readStateFromTree (TreeNode *) |
| Reads the object state from the children of the given parent node. More... | |
| virtual void | writeTo (AbstractPersistenceOutputStream *) const |
| Write the objects state to the data stream object. More... | |
| virtual void | readFrom (AbstractPersistenceInputStream *, int) |
| Read the objects state from the data stream object. More... | |
| Public Member Functions inherited from ml::FieldAddOnBase | |
| FieldAddOnBase (FieldContainer &fieldContainerRef) | |
| Constructor, setting the reference of the FieldContainer managing the fields. More... | |
| virtual | ~FieldAddOnBase () |
| Destructor. More... | |
| FieldContainer & | getFieldContainer () |
| Returns the referenced container. More... | |
| const FieldContainer & | getFieldContainer () const |
| Returns the referenced container. More... | |
| std::vector< Field * > & | getFields () |
| Return modification access to the list of managed fields, use at own risk! More... | |
| const std::vector< Field * > & | getFields () const |
| Return constant access to the list of managed fields! More... | |
| virtual FieldChangeState | getMergedFieldChangeState (FieldChangeState state1, FieldChangeState state2) const |
| Returns a FieldChangeState which best represents a merge of the two given states. More... | |
| virtual bool | hasField (Field *field) const |
| Returns true if the passed fieldPtr is in _fieldPointers, otherwise false. More... | |
Static Public Member Functions | |
| static bool | isIn (const std::string &str, const char *const *values, size_t numValues) |
| Static helper function which checks whether str is part of the given list of values which has numValues entries. More... | |
Additional Inherited Members | |
| Public Types inherited from ml::Base | |
| enum | PersistenceInterface { PersistenceByString , PersistenceByTreeNode , PersistenceByStream } |
| This enum describes the different persistence interfaces available. More... | |
| Public Types inherited from ml::FieldAddOnBase | |
| enum | FieldChangeState { NoChange = 0 , StatusOnlyChange , RecalculationRequired } |
| Describes the type of a field changes detected in handleFieldChanges(Field *field). More... | |
| Protected Member Functions inherited from ml::Base | |
| virtual char * | getPersistentState () const |
| Returns a C string describing the object's internal state. More... | |
| virtual void | setPersistentState (const char *) |
Restores the object's internal state from a string that had been previously generated using getPersistentState(). More... | |
| virtual void | clearPersistentState (char *) const |
Disposes a string previously allocated by getPersistentState(). More... | |
| Protected Member Functions inherited from ml::FieldAddOnBase | |
| void | _addFieldPointer (Field *field) |
| Helper routine to add a Field pointer to _fieldPointers, empty pointers and pointers added more than once will be handled fatally. More... | |
Detailed Description
The class DicomModifyFieldAddOnBase is dedicated to manage fields for ML modules and instances derived from DicomModifyBase to combine field handling and tag modification functionality to modify DCMTree's and to allow concatenation of them to pipelines.
Definition at line 29 of file mlDicomModifyFieldAddOnBase.h.
Constructor & Destructor Documentation
◆ DicomModifyFieldAddOnBase()
| ml::DicomModifyFieldAddOnBase::DicomModifyFieldAddOnBase | ( | FieldContainer & | fieldContainerRef, |
| size_t | numInstances = 1, |
||
| bool | createInputModifyTagsPluginBaseConnectorField = false, |
||
| bool | createOutputModifyTagsPluginBaseConnectorField = false |
||
| ) |
Constructor, setting the reference of the FieldContainer managing the fields, the number of field instances to create and optionally input and output fields to create modification pipelines.
- Parameters
-
fieldContainerRef the modifiable reference of the FieldContainer which shall be extended by this instance. numInstances the number of entries to be created. createInputModifyTagsPluginBaseConnectorField adds a Base input connector to the field container which which allows the connection of further DicomModifyList objects to be called from applyModifications(). createOutputModifyTagsPluginBaseConnectorField will add a Base output connector to the field container which
allows the connection of this to other DicomModifyList objects.
◆ ~DicomModifyFieldAddOnBase()
|
override |
Destructor resetting connector fields if they exist.
Member Function Documentation
◆ addFields()
|
overridevirtual |
Add fields to field container of the FieldAddOn.
Implements ml::FieldAddOnBase.
Reimplemented in ml::DicomModifyModuleFieldAddOnBase, ml::DicomModifyVOILUTModuleFieldAddOn, ml::DicomModifyStructureSetModuleFieldAddOn, ml::DicomModifySOPCommonModuleFieldAddOn, ml::DicomModifyRTTreatmentSummaryRecordModuleFieldAddOn, ml::DicomModifyRTTreatmentMachineRecordModuleFieldAddOn, ml::DicomModifyRTToleranceTablesModuleFieldAddOn, ml::DicomModifyRTSeriesModuleFieldAddOn, ml::DicomModifyRTROIObservationsModuleFieldAddOn, ml::DicomModifyRTPrescriptionModuleFieldAddOn, ml::DicomModifyRTPatientSetupModuleFieldAddOn, ml::DicomModifyRTIonToleranceTablesModuleFieldAddOn, ml::DicomModifyRTIonBeamsSessionRecordModuleFieldAddOn, ml::DicomModifyRTIonBeamsModuleFieldAddOn, ml::DicomModifyRTImageModuleFieldAddOn, ml::DicomModifyRTGeneralTreatmentRecordModuleFieldAddOn, ml::DicomModifyRTGeneralPlanModuleFieldAddOn, ml::DicomModifyRTFractionSchemeModuleFieldAddOn, ml::DicomModifyRTDVHModuleFieldAddOn, ml::DicomModifyRTDoseROIModuleFieldAddOn, ml::DicomModifyRTDoseModuleFieldAddOn, ml::DicomModifyRTBrachyApplicationSetupsModuleFieldAddOn, ml::DicomModifyRTBeamsModuleFieldAddOn, ml::DicomModifyROIContourModuleFieldAddOn, ml::DicomModifyPatientStudyModuleFieldAddOn, ml::DicomModifyPatientModuleFieldAddOn, ml::DicomModifyOverlayPlaneModuleFieldAddOn, ml::DicomModifyMultiFrameOverlayModuleFieldAddOn, ml::DicomModifyMultiFrameModuleFieldAddOn, ml::DicomModifyModalityLUTModuleFieldAddOn, ml::DicomModifyMeasuredDoseReferenceRecordModuleFieldAddOn, ml::DicomModifyImagePlaneModuleFieldAddOn, ml::DicomModifyImagePixelModuleFieldAddOn, ml::DicomModifyGeneralStudyModuleFieldAddOn, ml::DicomModifyGeneralImageModuleFieldAddOn, ml::DicomModifyGeneralEquipmentModuleFieldAddOn, ml::DicomModifyFrameOfReferenceModuleFieldAddOn, ml::DicomModifyDeviceModuleFieldAddOn, ml::DicomModifyContrastBolusModuleFieldAddOn, ml::DicomModifyClinicalTrialSubjectModuleFieldAddOn, ml::DicomModifyClinicalTrialStudyModuleFieldAddOn, ml::DicomModifyClinicalTrialSeriesModuleFieldAddOn, ml::DicomModifyCineModuleFieldAddOn, ml::DicomModifyCalculatedDoseReferenceRecordModuleFieldAddOn, ml::DicomModifyApprovalModuleFieldAddOn, ml::DicomValueInheritAndCreateTagInterface, ml::DicomValueComboBoxSelectorTagInterface, ml::DicomSpatialFiducialsModuleTagInterface, ml::DicomSOPInstanceReferenceMacroTagInterface, ml::DicomSOPCommonModuleTagInterface, ml::DicomSeriesAndInstanceReferenceMacroTagInterface, ml::DicomSegmentSequenceTagInterface, ml::DicomSegmentationSeriesModuleAttributesTagInterface, ml::DicomSegmentationImageModuleTagInterface, ml::DicomSCMultiframeImageModuleTagInterface, ml::DicomSCEquipmentModuleTagInterface, ml::DicomReferencedImageSequenceTagInterface, ml::DicomPatientModuleTagInterface, ml::DicomMRSeriesModuleTagInterface, ml::DicomManufacturing3DModelModuleTagInterface, ml::DicomImageTypeTagInterface, ml::DicomImagePlaneModuleTagInterface, ml::DicomImageDescriptionTagInterface, ml::DicomGeneralStudyModuleTagInterface, ml::DicomGeneralSeriesModuleTagInterface, ml::DicomGeneralImageModuleTagInterface, ml::DicomGeneralEquipmentModuleTagInterface, ml::DicomFrameOfReferenceModuleTagInterface, ml::DicomEnhancedMRImageModuleTagInterface, ml::DicomEncapsulatedDocumentSeriesModuleTagInterface, ml::DicomEncapsulatedDocumentModuleTagInterface, ml::DicomDeformableSpatialRegistrationModuleTagInterface, ml::DicomCopyTagSetInterface, ml::DicomCopyGroupsTagInterface, ml::DicomContentIdentificationMacroTagInterface, ml::DicomContentDateTimeTagInterface, ml::DicomCommonInstanceReferenceModuleTagInterface, ml::DicomCIDSingleEntryEditTagInterface, ml::DicomCIDEditTagInterface, ml::DicomBoolInheritAndWriteTagInterface, ml::DicomAcquisitionContextModuleTagInterface, ml::DicomModifyTagsVariousFieldAddOns, ml::DicomModifySubTreeSelectorFieldAddOn, ml::DicomModifySequenceFieldAddOn, ml::DicomModifyPrivateRemoveFieldAddOn, ml::DicomModifyPrivateAddFieldAddOn, ml::DicomModifyOtherTagOperationsFieldAddOn, ml::DicomModifyOrdinaryFieldAddOn, and ml::DicomModifyImageTagsFieldAddOn.
◆ applyModifications()
|
overridevirtual |
Applies first the changes to the dcmTree as described in DicomModifyList::applyModifications() and then calls applyModifications() on all connected input DicomModifyList objects.
- Parameters
-
dcmTree The DICOM tree to be modified. treeInfos A FieldContainer which - if not nullptr - can contain additional user defined information fields about dcmTree and the changes to perform.
- Returns
- An empty string on success, otherwise a cumulative descriptive string of all problems.
Reimplemented from ml::DicomModifyList.
Reimplemented in ml::DicomValueInheritAndCreateTagInterface, ml::DicomValueComboBoxSelectorTagInterface, ml::DicomSpatialFiducialsModuleTagInterface, ml::DicomSOPInstanceReferenceMacroTagInterface, ml::DicomSOPCommonModuleTagInterface, ml::DicomSeriesAndInstanceReferenceMacroTagInterface, ml::DicomSegmentSequenceTagInterface, ml::DicomSegmentationSeriesModuleAttributesTagInterface, ml::DicomSegmentationImageModuleTagInterface, ml::DicomSCMultiframeImageModuleTagInterface, ml::DicomSCEquipmentModuleTagInterface, ml::DicomReferencedImageSequenceTagInterface, ml::DicomPatientModuleTagInterface, ml::DicomMRSeriesModuleTagInterface, ml::DicomManufacturing3DModelModuleTagInterface, ml::DicomImageTypeTagInterface, ml::DicomImagePlaneModuleTagInterface, ml::DicomImageDescriptionTagInterface, ml::DicomGeneralStudyModuleTagInterface, ml::DicomGeneralSeriesModuleTagInterface, ml::DicomGeneralImageModuleTagInterface, ml::DicomGeneralEquipmentModuleTagInterface, ml::DicomFrameOfReferenceModuleTagInterface, ml::DicomEnhancedMRImageModuleTagInterface, ml::DicomEncapsulatedDocumentSeriesModuleTagInterface, ml::DicomEncapsulatedDocumentModuleTagInterface, ml::DicomDeformableSpatialRegistrationModuleTagInterface, ml::DicomCopyTagSetInterface, ml::DicomCopyGroupsTagInterface, ml::DicomContentIdentificationMacroTagInterface, ml::DicomContentDateTimeTagInterface, ml::DicomCommonInstanceReferenceModuleTagInterface, ml::DicomCIDSingleEntryEditTagInterface, ml::DicomCIDEditTagInterface, ml::DicomBoolInheritAndWriteTagInterface, ml::DicomAcquisitionContextModuleTagInterface, ml::DicomModifyTagsVariousFieldAddOns, ml::DicomModifyImageTagsFieldAddOn, ml::DicomModifyVOILUTModuleFieldAddOn, ml::DicomModifyStructureSetModuleFieldAddOn, ml::DicomModifySOPCommonModuleFieldAddOn, ml::DicomModifyRTTreatmentSummaryRecordModuleFieldAddOn, ml::DicomModifyRTTreatmentMachineRecordModuleFieldAddOn, ml::DicomModifyRTToleranceTablesModuleFieldAddOn, ml::DicomModifyRTSeriesModuleFieldAddOn, ml::DicomModifyRTROIObservationsModuleFieldAddOn, ml::DicomModifyRTPrescriptionModuleFieldAddOn, ml::DicomModifyRTPatientSetupModuleFieldAddOn, ml::DicomModifyRTIonToleranceTablesModuleFieldAddOn, ml::DicomModifyRTIonBeamsSessionRecordModuleFieldAddOn, ml::DicomModifyRTIonBeamsModuleFieldAddOn, ml::DicomModifyRTImageModuleFieldAddOn, ml::DicomModifyRTGeneralTreatmentRecordModuleFieldAddOn, ml::DicomModifyRTGeneralPlanModuleFieldAddOn, ml::DicomModifyRTFractionSchemeModuleFieldAddOn, ml::DicomModifyRTDVHModuleFieldAddOn, ml::DicomModifyRTDoseROIModuleFieldAddOn, ml::DicomModifyRTDoseModuleFieldAddOn, ml::DicomModifyRTBrachyApplicationSetupsModuleFieldAddOn, ml::DicomModifyRTBeamsModuleFieldAddOn, ml::DicomModifyROIContourModuleFieldAddOn, ml::DicomModifyPatientStudyModuleFieldAddOn, ml::DicomModifyPatientModuleFieldAddOn, ml::DicomModifyOverlayPlaneModuleFieldAddOn, ml::DicomModifyMultiFrameOverlayModuleFieldAddOn, ml::DicomModifyMultiFrameModuleFieldAddOn, ml::DicomModifyModalityLUTModuleFieldAddOn, ml::DicomModifyMeasuredDoseReferenceRecordModuleFieldAddOn, ml::DicomModifyImagePlaneModuleFieldAddOn, ml::DicomModifyImagePixelModuleFieldAddOn, ml::DicomModifyGeneralStudyModuleFieldAddOn, ml::DicomModifyGeneralImageModuleFieldAddOn, ml::DicomModifyGeneralEquipmentModuleFieldAddOn, ml::DicomModifyFrameOfReferenceModuleFieldAddOn, ml::DicomModifyDeviceModuleFieldAddOn, ml::DicomModifyContrastBolusModuleFieldAddOn, ml::DicomModifyClinicalTrialSubjectModuleFieldAddOn, ml::DicomModifyClinicalTrialStudyModuleFieldAddOn, ml::DicomModifyClinicalTrialSeriesModuleFieldAddOn, ml::DicomModifyCineModuleFieldAddOn, ml::DicomModifyCalculatedDoseReferenceRecordModuleFieldAddOn, ml::DicomModifyApprovalModuleFieldAddOn, and ml::DicomModifySubTreeSelectorFieldAddOn.
◆ checkConsistency()
|
inlinevirtual |
Checks for invalid parameters; return textual description on error, or empty string on success.
Reimplemented in ml::DicomModifyVOILUTModuleFieldAddOn, ml::DicomModifyStructureSetModuleFieldAddOn, ml::DicomModifySOPCommonModuleFieldAddOn, ml::DicomModifyRTTreatmentSummaryRecordModuleFieldAddOn, ml::DicomModifyRTTreatmentMachineRecordModuleFieldAddOn, ml::DicomModifyRTToleranceTablesModuleFieldAddOn, ml::DicomModifyRTSeriesModuleFieldAddOn, ml::DicomModifyRTROIObservationsModuleFieldAddOn, ml::DicomModifyRTPrescriptionModuleFieldAddOn, ml::DicomModifyRTPatientSetupModuleFieldAddOn, ml::DicomModifyRTIonToleranceTablesModuleFieldAddOn, ml::DicomModifyRTIonBeamsSessionRecordModuleFieldAddOn, ml::DicomModifyRTIonBeamsModuleFieldAddOn, ml::DicomModifyRTImageModuleFieldAddOn, ml::DicomModifyRTGeneralTreatmentRecordModuleFieldAddOn, ml::DicomModifyRTGeneralPlanModuleFieldAddOn, ml::DicomModifyRTFractionSchemeModuleFieldAddOn, ml::DicomModifyRTDVHModuleFieldAddOn, ml::DicomModifyRTDoseROIModuleFieldAddOn, ml::DicomModifyRTDoseModuleFieldAddOn, ml::DicomModifyRTBrachyApplicationSetupsModuleFieldAddOn, ml::DicomModifyRTBeamsModuleFieldAddOn, ml::DicomModifyROIContourModuleFieldAddOn, ml::DicomModifyPatientStudyModuleFieldAddOn, ml::DicomModifyPatientModuleFieldAddOn, ml::DicomModifyOverlayPlaneModuleFieldAddOn, ml::DicomModifyMultiFrameOverlayModuleFieldAddOn, ml::DicomModifyMultiFrameModuleFieldAddOn, ml::DicomModifyModalityLUTModuleFieldAddOn, ml::DicomModifyMeasuredDoseReferenceRecordModuleFieldAddOn, ml::DicomModifyImagePlaneModuleFieldAddOn, ml::DicomModifyImagePixelModuleFieldAddOn, ml::DicomModifyGeneralStudyModuleFieldAddOn, ml::DicomModifyGeneralImageModuleFieldAddOn, ml::DicomModifyGeneralEquipmentModuleFieldAddOn, ml::DicomModifyFrameOfReferenceModuleFieldAddOn, ml::DicomModifyDeviceModuleFieldAddOn, ml::DicomModifyContrastBolusModuleFieldAddOn, ml::DicomModifyClinicalTrialSubjectModuleFieldAddOn, ml::DicomModifyClinicalTrialStudyModuleFieldAddOn, ml::DicomModifyClinicalTrialSeriesModuleFieldAddOn, ml::DicomModifyCineModuleFieldAddOn, ml::DicomModifyCalculatedDoseReferenceRecordModuleFieldAddOn, ml::DicomModifyApprovalModuleFieldAddOn, ml::DicomValueInheritAndCreateTagInterface, ml::DicomSpatialFiducialsModuleTagInterface, ml::DicomSOPInstanceReferenceMacroTagInterface, ml::DicomSOPCommonModuleTagInterface, ml::DicomSeriesAndInstanceReferenceMacroTagInterface, ml::DicomSegmentSequenceTagInterface, ml::DicomSegmentationSeriesModuleAttributesTagInterface, ml::DicomSegmentationImageModuleTagInterface, ml::DicomSCMultiframeImageModuleTagInterface, ml::DicomSCEquipmentModuleTagInterface, ml::DicomReferencedImageSequenceTagInterface, ml::DicomPatientModuleTagInterface, ml::DicomMRSeriesModuleTagInterface, ml::DicomManufacturing3DModelModuleTagInterface, ml::DicomImageTypeTagInterface, ml::DicomImagePlaneModuleTagInterface, ml::DicomImageDescriptionTagInterface, ml::DicomGeneralStudyModuleTagInterface, ml::DicomGeneralSeriesModuleTagInterface, ml::DicomGeneralImageModuleTagInterface, ml::DicomGeneralEquipmentModuleTagInterface, ml::DicomFrameOfReferenceModuleTagInterface, ml::DicomEnhancedMRImageModuleTagInterface, ml::DicomEncapsulatedDocumentSeriesModuleTagInterface, ml::DicomEncapsulatedDocumentModuleTagInterface, ml::DicomDeformableSpatialRegistrationModuleTagInterface, ml::DicomCopyGroupsTagInterface, ml::DicomContentIdentificationMacroTagInterface, ml::DicomContentDateTimeTagInterface, ml::DicomCommonInstanceReferenceModuleTagInterface, ml::DicomCIDSingleEntryEditTagInterface, ml::DicomCIDEditTagInterface, ml::DicomBoolInheritAndWriteTagInterface, and ml::DicomAcquisitionContextModuleTagInterface.
Definition at line 79 of file mlDicomModifyFieldAddOnBase.h.
◆ getInputModifierListFld()
|
inline |
Provide access to input base connector field if it was created.
Definition at line 85 of file mlDicomModifyFieldAddOnBase.h.
◆ getNumInstances()
|
inline |
Returns the number of instances to be created by derived fields.
Definition at line 55 of file mlDicomModifyFieldAddOnBase.h.
◆ getOutputModifierListFld()
|
inline |
Provide access to output base field if it was created.
Definition at line 82 of file mlDicomModifyFieldAddOnBase.h.
◆ handleFieldActivationChanges()
|
overridevirtual |
Handle class changes according to Module::activateAttachments.
Reimplemented from ml::FieldAddOnBase.
Reimplemented in ml::DicomValueComboBoxSelectorTagInterface, ml::DicomSOPCommonModuleTagInterface, ml::DicomSegmentSequenceTagInterface, ml::DicomSegmentationImageModuleTagInterface, ml::DicomManufacturing3DModelModuleTagInterface, ml::DicomImageTypeTagInterface, ml::DicomImageDescriptionTagInterface, ml::DicomEnhancedMRImageModuleTagInterface, ml::DicomCIDSingleEntryEditTagInterface, ml::DicomCIDEditTagInterface, ml::DicomAcquisitionContextModuleTagInterface, ml::DicomModifyTagsVariousFieldAddOns, ml::DicomModifySubTreeSelectorFieldAddOn, ml::DicomModifySequenceFieldAddOn, ml::DicomModifyPrivateRemoveFieldAddOn, ml::DicomModifyPrivateAddFieldAddOn, ml::DicomModifyOtherTagOperationsFieldAddOn, and ml::DicomModifyOrdinaryFieldAddOn.
◆ handleFieldChanges()
|
overridevirtual |
Handle field notifications according to Module::handleNotification with a return of field change state.
Reimplemented from ml::FieldAddOnBase.
Reimplemented in ml::DicomModifyModuleFieldAddOnBase, ml::DicomValueInheritAndCreateTagInterface, ml::DicomValueComboBoxSelectorTagInterface, ml::DicomSOPCommonModuleTagInterface, ml::DicomSeriesAndInstanceReferenceMacroTagInterface, ml::DicomSegmentSequenceTagInterface, ml::DicomSegmentationImageModuleTagInterface, ml::DicomReferencedImageSequenceTagInterface, ml::DicomPatientModuleTagInterface, ml::DicomManufacturing3DModelModuleTagInterface, ml::DicomImageTypeTagInterface, ml::DicomImageDescriptionTagInterface, ml::DicomGeneralStudyModuleTagInterface, ml::DicomGeneralSeriesModuleTagInterface, ml::DicomGeneralEquipmentModuleTagInterface, ml::DicomEnhancedMRImageModuleTagInterface, ml::DicomEncapsulatedDocumentSeriesModuleTagInterface, ml::DicomCopyTagSetInterface, ml::DicomCopyGroupsTagInterface, ml::DicomCommonInstanceReferenceModuleTagInterface, ml::DicomCIDSingleEntryEditTagInterface, ml::DicomCIDEditTagInterface, ml::DicomBoolInheritAndWriteTagInterface, ml::DicomAcquisitionContextModuleTagInterface, ml::DicomModifyTagsVariousFieldAddOns, ml::DicomModifySubTreeSelectorFieldAddOn, ml::DicomModifySequenceFieldAddOn, ml::DicomModifyPrivateRemoveFieldAddOn, ml::DicomModifyPrivateAddFieldAddOn, ml::DicomModifyOtherTagOperationsFieldAddOn, and ml::DicomModifyOrdinaryFieldAddOn.
◆ inheritValues()
|
inlinevirtual |
Can be used to implement the copy of tag values from the given dcmTree to the fields.
Reimplemented in ml::DicomModifyVOILUTModuleFieldAddOn, ml::DicomModifyStructureSetModuleFieldAddOn, ml::DicomModifySOPCommonModuleFieldAddOn, ml::DicomModifyRTTreatmentSummaryRecordModuleFieldAddOn, ml::DicomModifyRTTreatmentMachineRecordModuleFieldAddOn, ml::DicomModifyRTToleranceTablesModuleFieldAddOn, ml::DicomModifyRTSeriesModuleFieldAddOn, ml::DicomModifyRTROIObservationsModuleFieldAddOn, ml::DicomModifyRTPrescriptionModuleFieldAddOn, ml::DicomModifyRTPatientSetupModuleFieldAddOn, ml::DicomModifyRTIonToleranceTablesModuleFieldAddOn, ml::DicomModifyRTIonBeamsSessionRecordModuleFieldAddOn, ml::DicomModifyRTIonBeamsModuleFieldAddOn, ml::DicomModifyRTImageModuleFieldAddOn, ml::DicomModifyRTGeneralTreatmentRecordModuleFieldAddOn, ml::DicomModifyRTGeneralPlanModuleFieldAddOn, ml::DicomModifyRTFractionSchemeModuleFieldAddOn, ml::DicomModifyRTDVHModuleFieldAddOn, ml::DicomModifyRTDoseROIModuleFieldAddOn, ml::DicomModifyRTDoseModuleFieldAddOn, ml::DicomModifyRTBrachyApplicationSetupsModuleFieldAddOn, ml::DicomModifyRTBeamsModuleFieldAddOn, ml::DicomModifyROIContourModuleFieldAddOn, ml::DicomModifyPatientStudyModuleFieldAddOn, ml::DicomModifyPatientModuleFieldAddOn, ml::DicomModifyOverlayPlaneModuleFieldAddOn, ml::DicomModifyMultiFrameOverlayModuleFieldAddOn, ml::DicomModifyMultiFrameModuleFieldAddOn, ml::DicomModifyModalityLUTModuleFieldAddOn, ml::DicomModifyMeasuredDoseReferenceRecordModuleFieldAddOn, ml::DicomModifyImagePlaneModuleFieldAddOn, ml::DicomModifyImagePixelModuleFieldAddOn, ml::DicomModifyGeneralStudyModuleFieldAddOn, ml::DicomModifyGeneralImageModuleFieldAddOn, ml::DicomModifyGeneralEquipmentModuleFieldAddOn, ml::DicomModifyFrameOfReferenceModuleFieldAddOn, ml::DicomModifyDeviceModuleFieldAddOn, ml::DicomModifyContrastBolusModuleFieldAddOn, ml::DicomModifyClinicalTrialSubjectModuleFieldAddOn, ml::DicomModifyClinicalTrialStudyModuleFieldAddOn, ml::DicomModifyClinicalTrialSeriesModuleFieldAddOn, ml::DicomModifyCineModuleFieldAddOn, ml::DicomModifyCalculatedDoseReferenceRecordModuleFieldAddOn, ml::DicomModifyApprovalModuleFieldAddOn, ml::DicomValueInheritAndCreateTagInterface, ml::DicomSpatialFiducialsModuleTagInterface, ml::DicomSOPInstanceReferenceMacroTagInterface, ml::DicomSOPCommonModuleTagInterface, ml::DicomSeriesAndInstanceReferenceMacroTagInterface, ml::DicomSegmentSequenceTagInterface, ml::DicomSegmentationSeriesModuleAttributesTagInterface, ml::DicomSegmentationImageModuleTagInterface, ml::DicomSCMultiframeImageModuleTagInterface, ml::DicomSCEquipmentModuleTagInterface, ml::DicomReferencedImageSequenceTagInterface, ml::DicomPatientModuleTagInterface, ml::DicomMRSeriesModuleTagInterface, ml::DicomManufacturing3DModelModuleTagInterface, ml::DicomImageTypeTagInterface, ml::DicomImagePlaneModuleTagInterface, ml::DicomImageDescriptionTagInterface, ml::DicomGeneralStudyModuleTagInterface, ml::DicomGeneralSeriesModuleTagInterface, ml::DicomGeneralImageModuleTagInterface, ml::DicomGeneralEquipmentModuleTagInterface, ml::DicomFrameOfReferenceModuleTagInterface, ml::DicomEnhancedMRImageModuleTagInterface, ml::DicomEncapsulatedDocumentSeriesModuleTagInterface, ml::DicomEncapsulatedDocumentModuleTagInterface, ml::DicomDeformableSpatialRegistrationModuleTagInterface, ml::DicomCopyTagSetInterface, ml::DicomCopyGroupsTagInterface, ml::DicomContentIdentificationMacroTagInterface, ml::DicomContentDateTimeTagInterface, ml::DicomCommonInstanceReferenceModuleTagInterface, ml::DicomCIDSingleEntryEditTagInterface, ml::DicomCIDEditTagInterface, ml::DicomBoolInheritAndWriteTagInterface, and ml::DicomAcquisitionContextModuleTagInterface.
Definition at line 76 of file mlDicomModifyFieldAddOnBase.h.
◆ isIn()
|
static |
Static helper function which checks whether str is part of the given list of values which has numValues entries.
The documentation for this class was generated from the following file:
- FMEstable/ReleaseMeVis/Projects/DICOM/MLDicomModify/Sources/mlDicomModifyFieldAddOnBase.h
