| | SoView2DAutoCenter () |
| |
| | ~SoView2DAutoCenter () override |
| |
| void | startDrawing (View2DSliceList *slicelist) override |
| | reimplemented from SoView2DExtension
|
| |
| bool | evalEvent (SoView2D *view2d, View2DSliceList *slicelist, View2DEvent *ec, View2DEventPhase phase) override |
| | reimplemented from SoView2DExtension
|
| |
| void | draw (View2DSliceList *slicelist, View2DSlice *slice, int sliceZ) override |
| | reimplemented from SoView2DExtension
|
| |
| | SoView2DInteractionExtension (const std::string &actionID, bool positionSensitive=true) |
| |
| | SoView2DInteractionExtension () |
| | Constructor.
|
| |
| bool | implementsManagedInteractionAndClassicEventHandling () const override |
| | this node is a hybrid module providing managed interaction and classic event handling
|
| |
| | SoView2DExtension () |
| | Constructor.
|
| |
| void | init () |
| | setup internal state
|
| |
| virtual void | updateValues () |
| | Update fields to local variables, may be reimplemented if you want to update additional local vars.
|
| |
| virtual void | endDrawing (View2DSliceList *) |
| |
| virtual void | overwriteDrawingSettings (SoView2DDrawingSettings &) |
| |
| View2DEvent * | getEvent () |
| | get the current event (when inside of evalEvent)
|
| |
| float | getSelectDist () |
| | Set the distance tolerance on hit checking in pixels.
|
| |
| bool | isPointInsideDeviceRect (float pointX, float pointY, float centerX, float centerY, float hitRectangleSize=0.0) |
| | returns whether the given point is inside a rectangle around the given center.
|
| |
| void | drawMiniRect (float xp, float yp, float ext, float lineWidth=1.f) |
| | Draws a small rectangle with given half side length and a line width.
|
| |
| void | drawDashedMiniRect (float xp, float yp, float ext, float lineWidth) |
| |
| void | drawFilledMiniRect (float xp, float yp, float ext, float lineWidth=1.f) |
| | Draws a small filled rectangle with given half side length.
|
| |
| void | drawMiniTriangle (float xp, float yp, float ext, float lineWidth=1.f) |
| | Draws a small triangle with given center point, half height and line width.
|
| |
| void | drawFilledMiniTriangle (float xp, float yp, float ext, float lineWidth=1.f) |
| | Draws a small filled triangle with given center point and half height.
|
| |
| void | drawMiniCircle (float xp, float yp, float ext, float lineWidth=1.f) |
| | Draws a small circle with given center point and radius.
|
| |
| void | drawFilledMiniCircle (float xp, float yp, float ext, float lineWidth=1.f) |
| | Draws a small filled circle with given center point and radius.
|
| |
| void | drawFixedSizeMiniCircleAt (float xp, float yp) |
| | Draws a fixed size small circle at the given position.
|
| |
| void | drawVoxelBorder (View2DSlice *slice, float vx, float vy, float vz) |
| | surround the given voxel with a border
|
| |
| int | getX () |
| | get the x device position of current event, only returns valid result when called inside of evalEvent()
|
| |
| int | getY () |
| | get the y device position of current event, only returns valid result when called inside of evalEvent()
|
| |
| virtual bool | isDrawingOn () |
| | check if drawing is on
|
| |
| virtual bool | isEditingOn () |
| | check if editing is on
|
| |
| virtual bool | isFixZOn () |
| | check if z should stay fixed
|
| |
| virtual bool | isClipToSlice () |
| | check if the image is clipped to slice
|
| |
| virtual void | fieldChanged (SoSensor *sensor) |
| | handle if any field has changed
|
| |
| bool | isCreateNewMode () |
| | check if extension is in createNewMode
|
| |
| void | setCreateNewMode (bool flag) |
| | set this extension to create new objects
|
| |
| bool | isCreateNewModeRequest () |
| | check if extension has a request for createNewMode
|
| |
| void | setCreateNewModeRequest (bool flag) |
| | set that extension want to become createNewMode
|
| |
| virtual bool | isActive () |
| | returns if the extension is active (derive this method in child) (in createNewMode or with a selected object)(called by SoView2D)
|
| |
| virtual void | deleteSelectedObject () |
| | deletes the currently active object (derive this method in child) (called by SoView2D)
|
| |
| virtual void | getStatusString (SbString &status) |
| | get the current status of this extension
|
| |
| virtual bool | evaluateEvent (SoView2D *view2d, View2DEvent *ec) |
| |
| virtual bool | ignoreEvent (View2DEvent *ec) |
| | Return true if ec has been handled before and if ignoreHandledEvents is True.
|
| |
| bool | wantsMouseOverUpdates () const |
| | public access to _wantsMouseOverUpdateEvents
|
| |
| virtual void | consumeEvent (View2DEvent *ec, bool handled=TRUE) |
| | Set handled-flag of ec to true (= consumed) if handled is True and setEventHandled is True.
|
| |
| int | getSelectedModifierMask () |
| | Get compare and ignore mask for the currently selected button/modifier combination, usable with SoPointingAction.
|
| |
| int | getSelectedIgnoreMask () |
| |
| SoPointingAction::Trigger | getPointingActionTriggerFromFields () |
| | Get the trigger that matches the button/modifier field state.
|
| |
| | SoInteractionProviderNode () |
| | Default constructor.
|
| |
| | ~SoInteractionProviderNode () override |
| | Destructor.
|
| |
| std::string | getID () const override |
| | Returns the ID string for identifying the provider and its actions.
|
| |
| void | objRef () override |
| | Memory management by reference counting; must be implemented in derived classes.
|
| |
| void | objUnref () override |
| |
| | SoInteractionOwner () |
| | Default constructor.
|
| |
| | ~SoInteractionOwner () override |
| | The destructor will destroy all interactions created with this object as owner.
|
| |
| std::list< SoInteraction * > | getInteractions (SoState *state) override |
| | Returns the list of all interactions of this provider.
|
| |
| void | pointerPosition (SoState *state, const SoPointerPosition &pos) override |
| | Same as below, with additional SoState argument. By default, simply calls the below version.
|
| |
| void | pointerLeftWindow (SoState *state) override |
| | Same as below, with additional SoState argument. By defaults, simply calls the below version.
|
| |
| void | addListener (SoInteractionOwnerListenerInterface *listener) |
| | Adds a listener object that is notified of changes in the interaction list.
|
| |
| void | removeListener (SoInteractionOwnerListenerInterface *listener) |
| | Removes a listener object that was notified of changes in the interaction list.
|
| |
| | SoInteractionProvider () |
| | Default constructor.
|
| |
| virtual | ~SoInteractionProvider () |
| |
| template<class T > |
| std::list< T * > | getInteractionsOfType (SoState *state) |
| | Returns list of interactions of a specific type.
|
| |
| virtual std::list< SoCommandAction * > | getCommandActions (SoState *state) |
| |
| virtual std::list< SoPointingAction * > | getPointingActions (SoState *state) |
| |
| virtual std::list< SoOffsetAction * > | getOffsetActions (SoState *state) |
| |
|
| static void | initClass () |
| |
| static void | timerSensorCB (void *data, SoSensor *sensor) |
| | Callback for timer sensor that is used for smooth zooming.
|
| |
| static void | initClass () |
| | Initializes this class.
|
| |
| static void | initClass () |
| | Initializes this class.
|
| |
| static float | snapToPixelCenter (float coordinateComponent) |
| | Snaps the coordinate component to the pixel center.
|
| |
| static void | fieldChangedCB (void *data, SoSensor *sensor) |
| | inventor callbacks if any field has changed, calls fieldChanged
|
| |
| static bool | isImageParallel (SoSFMLImage *image, View2DSliceList *dsl) |
| | Return true if image is parallel to the image of the slice list up to slice thickness.
|
| |
| static void | enableLineStippling (const SoSFEnum &lineStyleField) |
| | Set/reset stippling pattern.
|
| |
| static void | disableLineStippling (const SoSFEnum &lineStyleField) |
| |
| static void | getAxisOrientation (int axis, SbMatrix &matrix, char &negativeResult, char &positiveResult) |
| | Geometry helpers.
|
| |
| static float | pointToLineDistance (SbVec3f point, SbVec3f line1, SbVec3f line2) |
| | calculate 3D point to line distance
|
| |
| static float | pointToLineDistance (SbVec2f point, SbVec2f line1, SbVec2f line2) |
| | calculate 2D point to line distance
|
| |
| static Sign | edgeIntersectWithPlane (const SbVec3f &v1, const SbVec3f &v2, const SbPlane &plane, SbVec3f &intersect) |
| | intersect given edge from v1 to v2 with given plane, returns sign and intersect point
|
| |
| static void | initClass () |
| | Initializes this class.
|
| |
| static void | registerInteractionProviderNode (SoType type, GetProviderFunc func) |
| | Registers a function to obtain a SoInteractionProvider from a SoNode.
|
| |
| static SoInteractionProvider * | getInteractionProvider (SoNode *node) |
| | Returns a SoInteractionProvider from a SoNode if registered, else NULL.
|
| |
|
| SoSFTrigger | triggerResetZoom |
| | Triggering causes centering of the view.
|
| |
| SoSFTrigger | singleClicked |
| | this is triggered when the user clicks without moving the mouse (this only is supported when using Managed Interaction)
|
| |
| SoSFTrigger | doubleClicked |
| | the same for the second click in a row
|
| |
| SoSFColor | color |
| | color that should be used for drawing
|
| |
| SoSFBool | drawingOn |
| | flag if the extension should draw, needs to be checked inside of the draw() method
|
| |
| SoSFBool | editingOn |
| | flag if the extension should edit objects on mouse events, needs to be checked inside of the evalEvent() method
|
| |
| SoSFBool | maskValid |
| | flag if the event mask is valid.
|
| |
| SoSFFloat | selectionTolerance |
| | the selection tolerance in pixels
|
| |
| SoSFBool | wantsAllEvents |
| | flag if ALL events should be passed to evalEvent(), if disabled, events are only passed to evalEvent when the mouse mask gets valid
|
| |
| SoSFBool | wantsKeyEvents |
| | flag if keyboard events should be passed to evalEvent()
|
| |
| SoSFBool | wantsMouseWheelEvents |
| | flag if MouseWheel events should be passed to evalEvent()
|
| |
| SoSFBool | setEventHandled |
| | Set event handled if it is indeed handled by this extension.
|
| |
| SoSFBool | ignoreHandledEvents |
| | Ignore events, that have been handled by previous extensions.
|
| |
| SoSFEnum | button1 |
| | mouse mask for button1
|
| |
| SoSFEnum | button2 |
| | mouse mask for button2
|
| |
| SoSFEnum | button3 |
| | mouse mask for button3
|
| |
| SoSFEnum | shift |
| | shift modifier for mouse mask
|
| |
| SoSFEnum | control |
| | shift control for mouse mask
|
| |
| SoSFEnum | alt |
| | shift alt for mouse mask
|
| |
| SoSFBool | needsValidVoxel |
| | sets if a valid voxel must be hit to get evalEvent() calls
|
| |
| SoSFBool | renderOnSlab |
| | defines if the extension should be rendered on all slab slices
|
| |
| SoSFBool | createNewMode |
| | flag if extension is in createNewMode
|
| |
| SoSFTrigger | createNewModeRequest |
| |
| SoSFBool | clipToSlice |
| | Flag to clip drawing to slice.
|
| |
| SoSFEnum | cursorShape |
| | Set cursor shape if the mouse mask fits and mouseEvents are effectively sent to evalEvent for editing.
|
| |
| SoSFBool | fixZOn |
| | DEPRECATED flag that indicates that the extension should fix the z value, only used in SoView2DRectangle.
|
| |
| SoSFString | instanceName |
| | Defines interface field to store the instance name.
|
| |
| SoSFString | interactionProviderID |
| | This field overrides the instanceName as providerID if specified.
|
| |
Node that allows a View2D zoom fly in on mouse click.
Definition at line 23 of file SoView2DAutoCenter.h.
Public Member Functions inherited from SoView2DInteractionExtension
