ML Reference
|
ML integer image vector class to be specialized for different purposes. More...
#include <mlIntegerVector.h>
Public Types | |
enum | { NumberOfDimensions = ParentClass::NumberOfDimensions } |
Enumerator defining the dimension of this class. More... | |
typedef TVectorBase::ComponentType | ComponentType |
Integer type used by this vector. More... | |
typedef TVectorBase | ParentClass |
Parent class of this class. More... | |
Public Member Functions | |
std::string | print (const std::string &openStr="", const std::string &sepStr=" ", const std::string &termStr="", const MLint16 numDigits=-1) const |
Returns the string openStr + v.array[0] + sepStr + ... More... | |
Initialization | |
TVector () | |
Constructor. All components are initialized to 0. More... | |
TVector (const ComponentType i) | |
Constructor which initializes all components to i. More... | |
TVector (const TVector< TVectorBase > &v2) | |
TVector< TVectorBase > & | operator= (const TVector< TVectorBase > &v2) |
template<typename TVectorBase2 > | |
TVector (const TVector< TVectorBase2 > &v2) | |
Copy constructor from another TVector of same or other integer type, values are cast. More... | |
TVector (const ComponentType xp, const TVector &p) | |
Constructor which assigns X to x and copies other elements from p. More... | |
TVector (const MLint num, const ComponentType *const arr, const ComponentType deflt) | |
Constructor which initializes the vector components by copying them from arr[0] ,..., arr[num-1]. More... | |
void | copy (const MLint num, ComponentType *const arr) const |
Copy the first num elements from internal array into arr starting with array[0] to arr[0] to array[num-1] to arr[num-1], respectively. More... | |
void | set (const ComponentType v=0) |
Sets all components to v or - if v is not specified - to 0. More... | |
void | set (const TVector &v) |
Like assignment operator. More... | |
Functions and operators. | |
TVector< TVectorBase > | operator+ (const TVector &b) const |
Add the corresponding component from b to each component. More... | |
TVector< TVectorBase > & | operator+= (const TVector< TVectorBase > &b) |
Adds the corresponding component from b to each component. More... | |
TVector< TVectorBase > | operator- (const TVector< TVectorBase > &b) const |
Calculates and returns *this-b. More... | |
TVector< TVectorBase > & | operator-= (const TVector< TVectorBase > &b) |
Subtracts the corresponding component from b from each component. More... | |
TVector< TVectorBase > | operator* (const TVector< TVectorBase > &b) const |
Calculates and returns the multiplication of each component of this with its corresponding component from b. More... | |
TVector< TVectorBase > & | operator*= (const TVector< TVectorBase > &b) |
Multiplies each component with its corresponding components from b. More... | |
TVector< TVectorBase > | operator+ (const ComponentType b) const |
Calculates and returns the addition of each component of *this with scalar b. More... | |
TVector< TVectorBase > | operator- (const ComponentType b) const |
Subtracts the scalar b from all components. More... | |
TVector< TVectorBase > | operator* (const ComponentType b) const |
Multiplies all components with scalar b. More... | |
TVector< TVectorBase > | operator/ (const TVector< TVectorBase > &b) const |
Calculates and returns the division of each component of *this by its corresponding component from b. More... | |
TVector< TVectorBase > & | operator/= (const TVector< TVectorBase > &b) |
Divides each component by its corresponding component from b. More... | |
bool | operator== (const TVector< TVectorBase > &b) const |
Equality operator: Returns whether each component of a is equal to its corresponding component of b. More... | |
bool | operator!= (const TVector< TVectorBase > &b) const |
Inequality operator: Returns whether any component differs from its corresponding component of b. More... | |
bool | operator< (const TVector< TVectorBase > &b) const |
"Smaller" comparison operator, return whether the 'smaller' relation is valid for all components. More... | |
bool | operator<= (const TVector< TVectorBase > &b) const |
"Smaller Or Equal" comparison operator, return whether the 'smaller or equal' relation is valid for all components. More... | |
bool | operator> (const TVector< TVectorBase > &b) const |
"Greater" comparison operator, return whether the 'greater' relation is valid for all components. More... | |
bool | operator>= (const TVector< TVectorBase > &b) const |
"Greater or Equal" comparison operator, return whether the 'greater or equal' relation is valid for all components. More... | |
TVector< TVectorBase > | operator& (const TVector< TVectorBase > &b) const |
Performs a binary "And" of all components with the corresponding components of another Vector. More... | |
TVector< TVectorBase > | operator| (const TVector< TVectorBase > &b) const |
Performs a binary "Or" of all components with the corresponding components of another Vector. More... | |
TVector< TVectorBase > | operator^ (const TVector< TVectorBase > &b) const |
Performs a binary "Xor" of all components with the corresponding components of another Vector. More... | |
TVector< TVectorBase > & | operator&= (const TVector< TVectorBase > &b) |
Performs a binary "And" of all components with the corresponding components of another Vector. More... | |
TVector< TVectorBase > & | operator|= (const TVector< TVectorBase > &b) |
Performs a binary "Or" of all components with the corresponding components of another Vector. More... | |
TVector< TVectorBase > & | operator^= (const TVector< TVectorBase > &b) |
Performs a binary "Xor" of all components with the corresponding components of another Vector. More... | |
TVector< TVectorBase > | operator& (const ComponentType b) const |
Performs a binary "And" of all components with an integer. More... | |
TVector< TVectorBase > | operator| (const ComponentType b) const |
Performs a binary "Or" of all components with an integer. More... | |
TVector< TVectorBase > | operator^ (const ComponentType b) const |
Performs a binary "Xor" of all components with an integer. More... | |
TVector< TVectorBase > & | operator&= (const ComponentType b) |
Performs a binary "And" of all components with an integer. More... | |
TVector< TVectorBase > & | operator|= (const ComponentType b) |
Performs a binary "Or" of all components with an integer. More... | |
TVector< TVectorBase > & | operator^= (const ComponentType b) |
Performs a binary "Xor" of all components with an integer. More... | |
TVector< TVectorBase > | operator>> (const int b) const |
Performs a binary right shift ">>" on each vector component. More... | |
TVector< TVectorBase > | operator<< (const int b) const |
Performs a binary left shift "<<" on each vector component. More... | |
TVector< TVectorBase > & | operator>>= (const int b) |
Performs a binary right shift unary ">>=" on each vector component. More... | |
TVector< TVectorBase > & | operator<<= (const int b) |
Performs a binary left shift unary "<<=" on each vector component. More... | |
TVector< TVectorBase > | operator- () const |
Performs an unary "-" on each vector component. More... | |
ComponentType | operator[] (const size_t i) const |
Constant indexing operator permits read access to array[0], ..., array[NumberOfDimensions-1] via indexes 0,1, ..., NumberOfDimensions-1, respectively. More... | |
ComponentType & | operator[] (const size_t i) |
Indexing operator permits read and write access to array[0], ..., array[NumberOfDimensions-1] via indexes 0,1, ..., NumberOfDimensions-1, respectively. More... | |
MLint | getMaxIdx () const |
Searches the maximum component and returns the index of its first occurrence. More... | |
ComponentType | getMax () const |
Returns the maximum component value. More... | |
MLint | getMinIdx () const |
Searches the minimum component and returns the index of its first occurrence. More... | |
ComponentType | getMin () const |
Returns the minimum component value. More... | |
TVector< TVectorBase > | getStrides (const ComponentType offset=1) const |
Interprets the vector as image extension and returns a stride vector. More... | |
TVector< TVectorBase > | getVectorPosition (ComponentType offsetPos) const |
Interprets the vector as a stride vector of an image and returns the offset position offsetPos from the image origin to the coordinate specified by the vector. More... | |
MLint | getExtDimension () const |
Returns the index to the highest vector component which is not 1 which is useful to get the real dimensional extent of an image. More... | |
bool | hasNegativeComp () const |
Returns whether any component is negative. More... | |
bool | allBiggerZero () const |
Returns whether all components > 0. More... | |
Arithmetics as static and member functions | |
TVector< TVectorBase > | divCeil (const TVector< TVectorBase > &b) const |
Returns the component wise division of the vector this by vector b with rounding up. More... | |
TVector< TVectorBase > | compMin (const TVector< TVectorBase > &b) const |
Returns the component wise minimum of components of this and b. More... | |
TVector< TVectorBase > | compMax (const TVector< TVectorBase > &b) const |
Returns the component wise maximum of components of this and b. More... | |
TVector< TVectorBase > | compMod (const TVector< TVectorBase > &b) const |
Returns the rest of the division of this by b component wise. More... | |
TVector< TVectorBase > | compAbs () const |
Returns a vector with all components of this replaced by their absolute values. More... | |
ComponentType | compMul () const |
Returns the product of all components. There is no check for integer overflow. More... | |
ComponentType | compSum () const |
Returns the sum of all components. There is no check for integer overflow. More... | |
ComponentType | dot (const TVector< TVectorBase > &b) const |
Returns the scalar product of vectors this and b. There is no check for integer overflow. More... | |
void | fillSmallerComps (const ComponentType threshold=0, const ComponentType fillVal=0) |
Sets the components which are smaller than threshold to fillVal. More... | |
void | fillGreaterComps (const ComponentType threshold=0, const ComponentType fillVal=0) |
Sets the components which are greater than threshold to fillVal. More... | |
void | fillEqualComps (const ComponentType threshold=0, const ComponentType fillVal=0) |
Sets the components which are equal to threshold to fillVal. More... | |
static TVector< TVectorBase > | divCeil (const TVector< TVectorBase > &a, const TVector< TVectorBase > &b) |
Static version: Returns the component wise division of the vector a by vector b with rounding up. More... | |
static TVector< TVectorBase > | compMin (const TVector< TVectorBase > &a, const TVector< TVectorBase > &b) |
Static version: Returns the component wise minimum of vectors a and b. More... | |
static TVector< TVectorBase > | compMax (const TVector< TVectorBase > &a, const TVector< TVectorBase > &b) |
Static version: Returns the component wise maximum of vectors a and b. More... | |
static TVector< TVectorBase > | compMod (const TVector< TVectorBase > &a, const TVector< TVectorBase > &b) |
Static version: Returns the rest dividing vector a by b component wise. More... | |
static TVector< TVectorBase > | compAbs (const TVector< TVectorBase > &a) |
Static version: Returns a vector with all components of a replaced by their absolute values. More... | |
static ComponentType | compMul (const TVector< TVectorBase > &a) |
Static version: Returns the product of all components without check for integer overflow. More... | |
static ComponentType | compSum (const TVector< TVectorBase > &a) |
Static version: Returns the sum of all components without check for integer overflow. More... | |
static ComponentType | dot (const TVector< TVectorBase > &a, const TVector< TVectorBase > &b) |
Static version: Returns the scalar product of vectors a and b without check for integer overflow. More... | |
ML integer image vector class to be specialized for different purposes.
It is a template to handle and calculate with n dimensional cardinal coordinates and vectors.
It represents a vector to address coordinates and offsets into images. The methods provide elementary arithmetic vector operations and support the stride concept for efficient image addressing.
The members of this class define a ND vector of type integer which is specialized normally to the ImageVector class which has the MLMaxImageDimension (defined in mlImageVector.h) with MLint as component type.
This class can also be instantiated with higher NumberOfDimensions arguments or other CompIntType arguments to compile arbitrary dimensional vectors with an arbitrary integer base type.
Example for vector initialization:
Notes:
TVectorBase | should be TVector6DBase for 6D ML image vector types or TVectorNDBase for other dimensional vectors. |
Definition at line 110 of file mlIntegerVector.h.
typedef TVectorBase::ComponentType ml::TVector< TVectorBase >::ComponentType |
Integer type used by this vector.
Definition at line 115 of file mlIntegerVector.h.
typedef TVectorBase ml::TVector< TVectorBase >::ParentClass |
Parent class of this class.
Definition at line 118 of file mlIntegerVector.h.
anonymous enum |
Enumerator defining the dimension of this class.
Enumerator | |
---|---|
NumberOfDimensions |
Definition at line 121 of file mlIntegerVector.h.
|
inline |
Constructor. All components are initialized to 0.
Definition at line 129 of file mlIntegerVector.h.
|
inlineexplicit |
Constructor which initializes all components to i.
Definition at line 135 of file mlIntegerVector.h.
|
inline |
Definition at line 144 of file mlIntegerVector.h.
|
inlineexplicit |
Copy constructor from another TVector of same or other integer type, values are cast.
Only valid elements are copied if vectors have different lengths.
Definition at line 161 of file mlIntegerVector.h.
References ml::TVector< TVectorBase >::NumberOfDimensions.
|
inlineexplicit |
Constructor which assigns X to x and copies other elements from p.
Definition at line 180 of file mlIntegerVector.h.
|
explicit |
Constructor which initializes the vector components by copying them from arr[0] ,..., arr[num-1].
All other elements are initialized to the value deflt.
Definition at line 650 of file mlIntegerVector.h.
References ML_CHECK_THROW, and ml::TVector< TVectorBase >::NumberOfDimensions.
|
inline |
Returns whether all components > 0.
Definition at line 502 of file mlIntegerVector.h.
|
inline |
Returns a vector with all components of this replaced by their absolute values.
Definition at line 526 of file mlIntegerVector.h.
References ml::compAbs().
|
static |
Static version: Returns a vector with all components of a replaced by their absolute values.
Definition at line 767 of file mlIntegerVector.h.
|
static |
Static version: Returns the component wise maximum of vectors a and b.
Definition at line 742 of file mlIntegerVector.h.
|
inline |
Returns the component wise maximum of components of this and b.
Definition at line 521 of file mlIntegerVector.h.
References ml::compMax().
|
static |
Static version: Returns the component wise minimum of vectors a and b.
Definition at line 731 of file mlIntegerVector.h.
|
inline |
Returns the component wise minimum of components of this and b.
Definition at line 519 of file mlIntegerVector.h.
References ml::compMin().
|
static |
Static version: Returns the rest dividing vector a by b component wise.
Division by zero caused by zero components of b must be avoided by caller.
Definition at line 755 of file mlIntegerVector.h.
References ML_CHECK_THROW.
|
inline |
Returns the rest of the division of this by b component wise.
Division by zero caused by zero components of b must be avoided by caller.
Definition at line 524 of file mlIntegerVector.h.
|
inline |
Returns the product of all components. There is no check for integer overflow.
Definition at line 529 of file mlIntegerVector.h.
References ml::compMul().
|
inlinestatic |
Static version: Returns the product of all components without check for integer overflow.
Definition at line 550 of file mlIntegerVector.h.
|
inline |
Returns the sum of all components. There is no check for integer overflow.
Definition at line 531 of file mlIntegerVector.h.
|
inlinestatic |
Static version: Returns the sum of all components without check for integer overflow.
Definition at line 560 of file mlIntegerVector.h.
void ml::TVector< TVectorBase >::copy | ( | const MLint | num, |
ComponentType *const | arr | ||
) | const |
Copy the first num elements from internal array into arr starting with array[0] to arr[0] to array[num-1] to arr[num-1], respectively.
All other components are left unchanged. arr must have at least num entries and at most NumberOfDimensions elements are copied.
Definition at line 661 of file mlIntegerVector.h.
References ML_CHECK_THROW.
|
static |
Static version: Returns the component wise division of the vector a by vector b with rounding up.
Division by zero caused by zero components of b must be avoided by caller.
Definition at line 718 of file mlIntegerVector.h.
References ML_CHECK_THROW.
|
inline |
Returns the component wise division of the vector this by vector b with rounding up.
Division by zero caused by zero components of b must be avoided by caller.
Definition at line 517 of file mlIntegerVector.h.
|
inlinestatic |
Static version: Returns the scalar product of vectors a and b without check for integer overflow.
Definition at line 572 of file mlIntegerVector.h.
|
inline |
Returns the scalar product of vectors this and b. There is no check for integer overflow.
Definition at line 534 of file mlIntegerVector.h.
|
inline |
Sets the components which are equal to threshold to fillVal.
Definition at line 601 of file mlIntegerVector.h.
|
inline |
Sets the components which are greater than threshold to fillVal.
Definition at line 595 of file mlIntegerVector.h.
|
inline |
Sets the components which are smaller than threshold to fillVal.
Definition at line 583 of file mlIntegerVector.h.
MLint ml::TVector< TVectorBase >::getExtDimension |
Returns the index to the highest vector component which is not 1 which is useful to get the real dimensional extent of an image.
Definition at line 703 of file mlIntegerVector.h.
|
inline |
Returns the maximum component value.
Definition at line 454 of file mlIntegerVector.h.
|
inline |
Searches the maximum component and returns the index of its first occurrence.
Definition at line 443 of file mlIntegerVector.h.
|
inline |
Returns the minimum component value.
Definition at line 471 of file mlIntegerVector.h.
|
inline |
Searches the minimum component and returns the index of its first occurrence.
Definition at line 460 of file mlIntegerVector.h.
TVector< TVectorBase > ml::TVector< TVectorBase >::getStrides | ( | const ComponentType | offset = 1 | ) | const |
Interprets the vector as image extension and returns a stride vector.
The smallest stride (the x stride) is set to offset, i.e. an image voxel is assumed to have size = offset. So stride[0] = offset, stride[1] = offset*array[0], stride[2] = offset*array[0]*array[1], ..., etc.
Definition at line 673 of file mlIntegerVector.h.
Referenced by ml::TSubImage< DATATYPE >::copySubImageReorderColorPlanesToInterleaved(), ml::SubImage::setBox(), and ml::SubImage::setExtent().
TVector< TVectorBase > ml::TVector< TVectorBase >::getVectorPosition | ( | ComponentType | offsetPos | ) | const |
Interprets the vector as a stride vector of an image and returns the offset position offsetPos from the image origin to the coordinate specified by the vector.
For offsetPos, an image with extents given by *this and the return value rv then holds:
)
Definition at line 687 of file mlIntegerVector.h.
References ML_CHECK_THROW.
Referenced by ml::TSubImage< DATATYPE >::convertPointerToSubImagePosition().
|
inline |
Returns whether any component is negative.
Definition at line 495 of file mlIntegerVector.h.
|
inline |
Inequality operator: Returns whether any component differs from its corresponding component of b.
Definition at line 294 of file mlIntegerVector.h.
|
inline |
Performs a binary "And" of all components with an integer.
Definition at line 364 of file mlIntegerVector.h.
|
inline |
Performs a binary "And" of all components with the corresponding components of another Vector.
Definition at line 329 of file mlIntegerVector.h.
|
inline |
Performs a binary "And" of all components with an integer.
Definition at line 380 of file mlIntegerVector.h.
|
inline |
Performs a binary "And" of all components with the corresponding components of another Vector.
Definition at line 345 of file mlIntegerVector.h.
|
inline |
Multiplies all components with scalar b.
Definition at line 264 of file mlIntegerVector.h.
|
inline |
Calculates and returns the multiplication of each component of this with its corresponding component from b.
Definition at line 239 of file mlIntegerVector.h.
|
inline |
Multiplies each component with its corresponding components from b.
Definition at line 244 of file mlIntegerVector.h.
|
inline |
Calculates and returns the addition of each component of *this with scalar b.
Definition at line 250 of file mlIntegerVector.h.
|
inline |
Add the corresponding component from b to each component.
Definition at line 217 of file mlIntegerVector.h.
|
inline |
Adds the corresponding component from b to each component.
Definition at line 222 of file mlIntegerVector.h.
|
inline |
Performs an unary "-" on each vector component.
Definition at line 423 of file mlIntegerVector.h.
|
inline |
Subtracts the scalar b from all components.
Definition at line 257 of file mlIntegerVector.h.
|
inline |
Calculates and returns *this-b.
Definition at line 228 of file mlIntegerVector.h.
|
inline |
Subtracts the corresponding component from b from each component.
Definition at line 233 of file mlIntegerVector.h.
|
inline |
Calculates and returns the division of each component of *this by its corresponding component from b.
Definition at line 271 of file mlIntegerVector.h.
|
inline |
Divides each component by its corresponding component from b.
Definition at line 276 of file mlIntegerVector.h.
References ML_CHECK_THROW.
|
inline |
"Smaller" comparison operator, return whether the 'smaller' relation is valid for all components.
Definition at line 300 of file mlIntegerVector.h.
|
inline |
Performs a binary left shift "<<" on each vector component.
Definition at line 399 of file mlIntegerVector.h.
|
inline |
Performs a binary left shift unary "<<=" on each vector component.
Definition at line 410 of file mlIntegerVector.h.
|
inline |
"Smaller Or Equal" comparison operator, return whether the 'smaller or equal' relation is valid for all components.
Definition at line 307 of file mlIntegerVector.h.
|
inline |
Definition at line 149 of file mlIntegerVector.h.
|
inline |
Equality operator: Returns whether each component of a is equal to its corresponding component of b.
Definition at line 286 of file mlIntegerVector.h.
|
inline |
"Greater" comparison operator, return whether the 'greater' relation is valid for all components.
Definition at line 314 of file mlIntegerVector.h.
|
inline |
"Greater or Equal" comparison operator, return whether the 'greater or equal' relation is valid for all components.
Definition at line 321 of file mlIntegerVector.h.
|
inline |
Performs a binary right shift ">>" on each vector component.
Definition at line 399 of file mlIntegerVector.h.
|
inline |
Performs a binary right shift unary ">>=" on each vector component.
Definition at line 410 of file mlIntegerVector.h.
|
inline |
Indexing operator permits read and write access to array[0], ..., array[NumberOfDimensions-1] via indexes 0,1, ..., NumberOfDimensions-1, respectively.
The caller must guarantee that i is within [0,...,NumberOfDimensions-1].
Definition at line 440 of file mlIntegerVector.h.
|
inline |
Constant indexing operator permits read access to array[0], ..., array[NumberOfDimensions-1] via indexes 0,1, ..., NumberOfDimensions-1, respectively.
The caller must guarantee that i is within [0,...,NumberOfDimensions-1].
Definition at line 434 of file mlIntegerVector.h.
|
inline |
Performs a binary "Xor" of all components with an integer.
Definition at line 374 of file mlIntegerVector.h.
|
inline |
Performs a binary "Xor" of all components with the corresponding components of another Vector.
Definition at line 339 of file mlIntegerVector.h.
|
inline |
Performs a binary "Xor" of all components with an integer.
Definition at line 392 of file mlIntegerVector.h.
|
inline |
Performs a binary "Xor" of all components with the corresponding components of another Vector.
Definition at line 357 of file mlIntegerVector.h.
|
inline |
Performs a binary "Or" of all components with an integer.
Definition at line 369 of file mlIntegerVector.h.
|
inline |
Performs a binary "Or" of all components with the corresponding components of another Vector.
Definition at line 334 of file mlIntegerVector.h.
|
inline |
Performs a binary "Or" of all components with an integer.
Definition at line 386 of file mlIntegerVector.h.
|
inline |
Performs a binary "Or" of all components with the corresponding components of another Vector.
Definition at line 351 of file mlIntegerVector.h.
std::string ml::TVector< TVectorBase >::print | ( | const std::string & | openStr = "" , |
const std::string & | sepStr = " " , |
||
const std::string & | termStr = "" , |
||
const MLint16 | numDigits = -1 |
||
) | const |
Returns the string openStr + v.array[0] + sepStr + ...
Definition at line 780 of file mlIntegerVector.h.
|
inline |
Sets all components to v or - if v is not specified - to 0.
Definition at line 198 of file mlIntegerVector.h.
|
inline |
Like assignment operator.
Definition at line 204 of file mlIntegerVector.h.
